Use Mailx to send emails using office 365

just something that came up while setting up a monitoring script using mailx, figured ill note it down here so i can get it to easily later when I need it 😀

Important prerequisites

  • You need to enable smtp basic Auth on Office 365 for the account used for authentication
  • Create an App password for the user account
  • nssdb folder must be available and readable by the user running the mailx command

Assuming all of the above prerequisite are $true we can proceed with the setup

Install mailx

RHEL/Alma linux

sudo dnf install mailx

NSSDB Folder

make sure the nssdb folder must be available and readable by the user running the mailx command

certutil -L -d /etc/pki/nssdb

The Output might be empty, but that’s ok; this is there if you need to add a locally signed cert or another CA cert manually, Microsoft Certs are trusted by default if you are on an up to date operating system with the local System-wide Trust Store

Reference – RHEL-sec-shared-system-certificates

Configure Mailx config file

sudo nano /etc/mail.rc

Append/prepend the following lines and Comment out or remove the same lines already defined on the existing config files

set smtp-auth-user=###[email protected]###
set smtp-auth-password=##Office365-App-password#
set nss-config-dir=/etc/pki/nssdb/
set ssl-verify=ignore
set smtp-use-starttls
set from="###[email protected]###"

This is the bare minimum needed other switches are located here – link


echo "Your message is sent!" | mailx -v -s "test" [email protected]

-v switch will print the verbos debug log to console

Connecting to . . . connected.
220 Microsoft ESMTP MAIL Service ready at Sun, 6 Aug 2023 22:14:56 +0000
>>> EHLO vls-xxx.multicastbits.local Hello []
250-SIZE 157286400
220 2.0.0 SMTP server ready
>>> EHLO vls-xxx.multicastbits.local Hello []
250-SIZE 157286400
334 VXNlcm5hbWU6
>>> Zxxxxxxxxxxxc0BmdC1zeXMuY29t
334 UGsxxxxxmQ6
>>> c2Rxxxxxxxxxxducw==
235 2.7.0 Authentication successful
>>> MAIL FROM:<###[email protected]###>
250 2.1.0 Sender OK
>>> RCPT TO:<[email protected]>
250 2.1.5 Recipient OK
>>> DATA
354 Start mail input; end with <CRLF>.<CRLF>
>>> .
250 2.0.0 OK <[email protected]> []
>>> QUIT
221 2.0.0 Service closing transmission channel

Now you can use this in your automation scripts or timers using the mailx command


recipient="[email protected]"
subject="Log file from /etc/app/runtime.log"

# Check if the log file exists
if [ ! -f "$log_file" ]; then
  echo "Error: Log file not found: $log_file"
  exit 1

# Use mailx to send the log file as an attachment
echo "Sending log file..."
mailx -s "$subject" -a "$log_file" -r "[email protected]" "$recipient" < /dev/null
echo "Log file sent successfully."

Secure it

sudo chown root:root /etc/mail.rc
sudo chmod 600 /etc/mail.rc

The above commands change the file’s owner and group to root, then set the file permissions to 600, which means only the owner (root) has read and write permissions and other users have no access to the file.

Use Environment Variables: Avoid storing sensitive information like passwords directly in the mail.rc file, consider using environment variables for sensitive data and reference those variables in the configuration.

For example, in the mail.rc file, you can set:

set smtp-auth-password=$MY_EMAIL_PASSWORD

You can set the variable using another config file or store it in the Ansible vault during runtime or use something like Hashicorp.

Sure, I would just use Python or PowerShell core, but you will run into more locked-down environments like OCI-managed DB servers with only Mailx is preinstalled and the only tool you can use 🙁

the Fact that you are here means you are already in the same boat. Hope this helped… until next time

Solution – RKE Cluster MetalLB provides Services with IP Addresses but doesn’t ARP for the address

I ran in to the the same issue detailed here working with a RKE cluster

After looking around for a few hours digging in to the logs i figured out the issue, hopefully this helps some one else our there in the situation save some time.

Make sure the IPVS mode is enabled on the cluster configuration

If you are using :

RKE2 – edit the cluster.yaml file

RKE1 – Edit the cluster configuration from the rancher UI > Cluster management > Select the cluster > edit configuration > edit as YAML

Locate the services field under rancher_kubernetes_engine_config and add the following options to enable IPVS

        ipvs-scheduler: lc
        proxy-mode: ipvs


After changes

Make sure the Kernel modules are enabled on the nodes running control planes


Example Rancher – RKE1 cluster

sudo docker ps | grep proxy # find the container ID for kubproxy

sudo docker logs ####containerID###

0313 21:44:08.315888  108645 feature_gate.go:245] feature gates: &{map[]}
I0313 21:44:08.346872  108645 proxier.go:652] "Failed to load kernel module with modprobe, you can ignore this message when kube-proxy is running inside container without mounting /lib/modules" moduleName="nf_conntrack_ipv4"
E0313 21:44:08.347024  108645 server_others.go:107] "Can't use the IPVS proxier" err="IPVS proxier will not be used because the following required kernel modules are not loaded: [ip_vs_lc]"

Kubproxy is trying to load the needed kernel modules and failing to enable IPVS

Lets enable the kernel modules

sudo nano /etc/modules-load.d/ipvs.conf


Install ipvsadm to confirm the changes

sudo dnf install ipvsadm -y

Reboot the VM or the Baremetal server

use the sudo ipvsadm to confirm ipvs is enabled

sudo ipvsadm


kubectl get svc -n #namespace | grep load
arping -I ens192
ARPING from ens192
Unicast reply from [00:50:56:96:E3:1D] 1.117ms
Unicast reply from [00:50:56:96:E3:1D] 0.737ms
Unicast reply from [00:50:56:96:E3:1D] 0.845ms
Unicast reply from [00:50:56:96:E3:1D] 0.668ms
Sent 4 probes (1 broadcast(s))
Received 4 response(s)

If you have the service type load balancer on a deployment now you should be able to reach it if the container is responding on the service

helpful Links

How to extend root (cs-root) Filesystem using LVM Cent OS/RHEL/Almalinux

This guide will walk you through on how to extend and increase space for the root filesystem on a alma linux. Cent OS, REHL Server/Desktop/VM

Method A – Expanding the current disk

Edit the VM and Add space to the Disk

install the cloud-utils-growpart package, as the growpart command in it makes it really easy to extend partitioned virtual disks.

sudo dnf install cloud-utils-growpart

Verify that the VM’s operating system recognizes the new increased size of the sda virtual disk, using lsblk or fdisk -l

sudo fdisk -l
Notes -
Note down the disk id and the partition number for Linux LVM - in this demo disk id is sda and lvm partition is sda 3

lets trigger a rescan of a block devices (Disks)

#elevate to root
sudo su

#trigger a rescan, Make sure to match the disk ID you noted down before
echo 1 > /sys/block/sda/device/rescan

Now sudo fdisk -l shows the correct size of the disks

Use growpart to increase the partition size for the lvm

sudo growpart /dev/sda 3

Confirm the volume group name

sudo vgs

Extend the logical volume

sudo lvextend -l +100%FREE /dev/almalinux/root

Grow the file system size

sudo xfs_growfs /dev/almalinux/root
Notes -
You can use this same steps to add space to different partitions such as home, swap if needed

Method B -Adding a second Disk to the LVM and expanding space

Why add a second disk?
may be the the current Disk is locked due to a snapshot and you cant remove it, Only solution would be to add a second disk/

Check the current space available

sudo df -h
Notes -
If you have 0% ~1MB left on the cs-root command auto-complete with tab and some of the later commands wont work, You should clear up atleast 4-10mb by clearing log files, temp files, etc

Mount an additional disk to the VM (Assuming this is a VM) and make sure the disk is visible on the OS level

sudo lvmdiskscan


sudo fdisk -l

Confirm the volume group name

sudo vgs

Lets increase the space

First lets initialize the new disk we mounted

sudo mkfs.xfs /dev/sdb

Create the Physical volume

sudo pvcreate /dev/sdb

extend the volume group

sudo vgextend cs /dev/sdb
  Volume group "cs" successfully extended

Extend the logical volume

sudo lvextend -l +100%FREE /dev/cs/root

Grow the file system size

sudo xfs_growfs /dev/cs/root

Confirm the changes

sudo df -h

Just making easy for us!!

#Method A - Expanding the current disk
sudo dnf install cloud-utils-growpart

sudo lvmdiskscan
sudo fdisk -l                          #note down the disk ID and partition num

sudo su                                #elevate to root
echo 1 > /sys/block/sda/device/rescan  #trigger a rescan
exit                                   #exit root shell

sudo lvextend -l +100%FREE /dev/almalinux/root
sudo xfs_growfs /dev/almalinux/root
sudo df -h

#Method B - Adding a second Disk

sudo lvmdiskscan
sudo fdisk -l
sudo vgs
sudo mkfs.xfs /dev/sdb
sudo pvcreate /dev/sdb
sudo vgextend cs /dev/sdb
sudo lvextend -l +100%FREE /dev/cs/root
sudo xfs_growfs /dev/cs/root
sudo df -h


sudo lvmdiskscan
sudo fdisk -l
sudo vgs
sudo mkfs.xfs /dev/sdb
sudo pvcreate /dev/sdb
sudo vgextend almalinux /dev/sdb
sudo lvextend -l +100%FREE /dev/almalinux/root
sudo xfs_growfs /dev/almalinux/root
sudo df -h

Setup guide for VSFTPD FTP Server – SELinux enforced with fail2ban (RHEL, CentOS, Almalinux)

Few things to note

  • if you want to prevent directory traversal we need to setup chroot with vsftpd (not covered on this KB)
  • For the demo I just used Unencrypted FTP on port 21 to keep things simple, Please utilize SFTP with the letsencrypt certificate for better security. i will cover this on another article and link it here

Update and Install packages we need

sudo dnf update
sudo dnf install net-tools lsof unzip zip tree policycoreutils-python-utils-2.9-20.el8.noarch vsftpd nano setroubleshoot-server -y

Setup Groups and Users and security hardening

if you want to prevent directory traversal we need to setup chroot with vsftpd (not covered on this KB)

Create the Service admin account

sudo useradd ftpadmin
sudo passwd ftpadmin

Create the group

sudo groupadd FTP_Root_RW

Create FTP only user shell for the FTP users

echo -e '#!/bin/sh\necho "This account is limited to FTP access only."' | sudo tee -a /bin/ftponly
sudo chmod a+x /bin/ftponly

echo "/bin/ftponly" | sudo tee -a /etc/shells

Create FTP users

sudo useradd ftpuser01 -m -s /bin/ftponly
sudo useradd ftpuser02 -m -s /bin/ftponly
user passwd ftpuser01
user passwd ftpuser02

Add the users to the group

sudo usermod -a -G FTP_Root_RW ftpuser01
sudo usermod -a -G FTP_Root_RW ftpuser02

sudo usermod -a -G FTP_Root_RW ftpadmin

Disable SSH Access for the FTP users.

Edit sshd_config

sudo nano /etc/ssh/sshd_config

Add the following line to the end of the file

DenyUsers ftpuser01 ftpuser02

Open ports on the VM Firewall

sudo firewall-cmd --permanent --add-port=20-21/tcp

#Allow the passive Port-Range we will define it later on the vsftpd.conf
sudo firewall-cmd --permanent --add-port=60000-65535/tcp

#Reload the ruleset
sudo firewall-cmd --reload

Setup the Second Disk for FTP DATA

Attach another disk to the VM and reboot if you haven’t done this already

lsblk to check the current disks and partitions detected by the system


Create the XFS partition

sudo mkfs.xfs /dev/sdb
# use mkfs.ext4 for ext4

Why XFS?

Create the folder for the mount point

sudo mkdir /FTP_DATA_DISK

Update the etc/fstab file and add the following line

sudo nano etc/fstab
/dev/sdb /FTP_DATA_DISK xfs defaults 1 2

Mount the disk

sudo mount -a


mount | grep sdb

Setup the VSFTPD Data and Log Folders

Setup the FTP Data folder

sudo mkdir /FTP_DATA_DISK/FTP_Root -p

Create the log directory

sudo mkdir /FTP_DATA_DISK/_logs/ -p

Set permissions

sudo chgrp -R FTP_Root_RW /FTP_DATA_DISK/FTP_Root/
sudo chmod 775 -R /FTP_DATA_DISK/FTP_Root/

Setup the VSFTPD Config File

Backup the default vsftpd.conf and create a newone

sudo mv /etc/vsftpd/vsftpd.conf /etc/vsftpd/vsftpdconfback
sudo nano /etc/vsftpd/vsftpd.conf
#KB Link - ####

ftpd_banner=Welcome to multicastbits Secure FTP service.




Add the FTP users to the userlist file

Backup the Original file

sudo mv /etc/vsftpd/user_list /etc/vsftpd/user_listBackup
echo "ftpuser01" | sudo tee -a /etc/vsftpd/user_list
echo "ftpuser02" | sudo tee -a /etc/vsftpd/user_list
sudo systemctl start vsftpd

sudo systemctl enable vsftpd

sudo systemctl status vsftpd

Setup SELinux

instead of putting our hands up and disabling SElinux, we are going to setup the policies correctly

Find the available policies using getsebool -a | grep ftp

getsebool -a | grep ftp

ftpd_anon_write --> off
ftpd_connect_all_unreserved --> off
ftpd_connect_db --> off
ftpd_full_access --> off
ftpd_use_cifs --> off
ftpd_use_fusefs --> off
ftpd_use_nfs --> off
ftpd_use_passive_mode --> off
httpd_can_connect_ftp --> off
httpd_enable_ftp_server --> off
tftp_anon_write --> off
tftp_home_dir --> off
[lxadmin@vls-BackendSFTP02 _logs]$
[lxadmin@vls-BackendSFTP02 _logs]$
[lxadmin@vls-BackendSFTP02 _logs]$ getsebool -a | grep ftp
ftpd_anon_write --> off
ftpd_connect_all_unreserved --> off
ftpd_connect_db --> off
ftpd_full_access --> off
ftpd_use_cifs --> off
ftpd_use_fusefs --> off
ftpd_use_nfs --> off
ftpd_use_passive_mode --> off
httpd_can_connect_ftp --> off
httpd_enable_ftp_server --> off
tftp_anon_write --> off
tftp_home_dir --> off

Set SELinux boolean values

sudo setsebool -P ftpd_use_passive_mode on

sudo setsebool -P ftpd_use_cifs on

sudo setsebool -P ftpd_full_access 1

    "setsebool" is a tool for setting SELinux boolean values, which control various aspects of the SELinux policy.

    "-P" specifies that the boolean value should be set permanently, so that it persists across system reboots.

    "ftpd_use_passive_mode" is the name of the boolean value that should be set. This boolean value controls whether the vsftpd FTP server should use passive mode for data connections.

    "on" specifies that the boolean value should be set to "on", which means that vsftpd should use passive mode for data connections.

    Enable ftp_home_dir --> on if you are using chroot

Add a new file context rule to the system.

sudo semanage fcontext -a -t public_content_rw_t "/FTP_DATA_DISK/FTP_Root/(/.*)?"
    "fcontext" is short for "file context", which refers to the security context that is associated with a file or directory.

    "-a" specifies that a new file context rule should be added to the system.

    "-t" specifies the new file context type that should be assigned to files or directories that match the rule.

    "public_content_rw_t" is the name of the new file context type that should be assigned to files or directories that match the rule. In this case, "public_content_rw_t" is a predefined SELinux type that allows read and write access to files and directories in public directories, such as /var/www/html.

    "/FTP_DATA_DISK/FTP_Root/(/.)?" specifies the file path pattern that the rule should match. The pattern includes the "/FTP_DATA_DISK/FTP_Root/" directory and any subdirectories or files beneath it. The regular expression "/(.)?" matches any file or directory name that may follow the "/FTP_DATA_DISK/FTP_Root/" directory path.

In summary, this command sets the file context type for all files and directories under the "/FTP_DATA_DISK/FTP_Root/" directory and its subdirectories to "public_content_rw_t", which allows read and write access to these files and directories.

Reset the SELinux security context for all files and directories under the “/FTP_DATA_DISK/FTP_Root/”

sudo restorecon -Rvv /FTP_DATA_DISK/FTP_Root/
    "restorecon" is a tool that resets the SELinux security context for files and directories to their default values.

    "-R" specifies that the operation should be recursive, meaning that the security context should be reset for all files and directories under the specified directory.

    "-vv" specifies that the command should run in verbose mode, which provides more detailed output about the operation.

"/FTP_DATA_DISK/FTP_Root/" is the path of the directory whose security context should be reset.

Setup Fail2ban

Install fail2ban

sudo dnf install fail2ban

Create the jail.local file

This file is used to overwrite the config blocks in /etc/fail2ban/fail2ban.conf
sudo nano /etc/fail2ban/jail.local
enabled = true
port = ftp,ftp-data,ftps,ftps-data
logpath = /FTP_DATA_DISK/_logs/vsftpd.log
maxretry = 5
bantime = 7200

Make sure to update the logpath directive to match the vsftpd log file we defined on the vsftpd.conf file

sudo systemctl start fail2ban

sudo systemctl enable fail2ban

sudo systemctl status fail2ban
journalctl -u fail2ban  will help you narrow down any issues with the service


sudo tail -f /var/log/fail2ban.log

Fail2ban injects and manages the following rich rules

Client will fail to connect using FTP until the ban is lifted

Remove the ban IP list

#get the list of banned IPs
sudo fail2ban-client get vsftpd banned

#Remove a specific IP from the list
sudo fail2ban-client set vsftpd unbanip <IP>

#Remove/Reset all the the banned IP lists
sudo fail2ban-client unban --all

This should get you up and running, For the demo I just used Unencrypted FTP on port 21 to keep things simple, Please utilize SFTP with the letsencrypt certificate for better security. i will cover this on another article and link it here

External Pi-hole with IPv6 – Setup a secured Pi-hole DNS service on Docker using Linode/AWS

Let me address the question of why I decided to put a DNS server (Pihole) exposed to the internet (not fully open but still).

I needed/wanted to set up an Umbrella/NextDNS/CF type DNS server that’s publicly accessible but secured to certain IP addresses.

Sure NextDNS is an option and its cheap with similar features, but i wanted roll my own solution so i can learn a few things along the way

I can easily set this up for my family members with minimal technical knowledge and unable to deal with another extra device (Raspberry pi) plugged into their home network.

This will also serve as a quick and dirty guide on how to use Docker compose and address some Issues with Running Pi-hole, Docker with UFW on Ubuntu 20.x

So lets get stahhhted…….


  • Setup Pi-hole as a docker container on a VM
  • Enable IPV6 support
  • Setup UFW rules to prune traffic and a cronjob to handle the rules to update with the dynamic WAN IPs
  • Deploy and test

What we need

  • Linux VM (Ubuntu, Hardened BSD, etc)
  • Docker and Docker Compose
  • Dynamic DNS service to track the changing IP (Dyndns,no-Ip, etc)


Setup Dynamic DNS solution to track your Dynamic WAN IP

for this demo, we are going to use DynDNS since I already own a paid account and its supported on most platforms (Routers, UTMs, NAS devices, IP camera-DVRs, etc)

Use some google-fu there are multiple ways to do this without having to pay for the service, all we need is a DNS record that's up-to-date with your current Public IP address.

For Network A and Network B, I’m going to use the routers built-in DDNS update features

Network A gateway – UDM Pro

Network B Gateway – Netgear R6230


Setup the VM with Docker-compose

Pick your service provider, you can and should be able to use a free tier VM for this since its just DNS

  • Linode
  • AWS lightsail
  • IBM cloud
  • Oracle cloud
  • Google Compute
  • Digital Ocean droplet

Make sure you have a dedicated (static) IPv4 and IPv6 address attached to the resource

For this deployment, I’m going to use a Linode – Nanode, due to their native IPv6 support and cause I prefer their platform for personal projects

Setup your Linode VM – Getting started Guide

SSH in to the VM or use weblish console

Update your packages and sources

sudo apt-get update
install Docker and Docker Compose

Assuming you already have SSH access to the VM with a static IPv4 and IPv6 address

Guide to installing Docker Engine on Ubuntu

Guide to Installing Docker-Compose

Once you have this setup confirm the docker setup

docker-compose version

Setup the Pi-hole Docker Image

Lets Configure the docker networking side to fit our Needs

Create a Seperate Bridge network for the Pi-hole container

I guess you could use the default bridge network, but I like to create one to keep things organized and this way this service can be isolated from the other containers I have

docker network create --ipv6 --driver bridge --subnet "fd01::/64" Piholev6


We will use this network later in docker compose

With the new ubuntu version 20.x, Systemd will start a local DNS stub client that runs on

which will prevent the container from starting. because Pi-hole binds to the same port UDP 53

we could disable the service but that breaks DNS resolution on the VM causing more headaches and pain for automation and updates

After some google fu and trickering around this this is the workaround i found.

  • Disable the stub-listener
  • Change the symlink to the /etc/resolved.conf to /run/systemd/resolve/resolv.conf
  • push the external name servers so the VM won’t look at loopback to resolve DNS
  • Restart systemd-resolved
Resolving Conflicts with the systemd-resolved stub listener

We need to disable the stub listener thats bound to port 53, as i mentioned before this breaks the local dns resolution we will fix it in a bit.

sudo nano /etc/systemd/resolved.conf

Find and uncomment the line “DNSStubListener=yes” and change it to “no”

After this we need to push the external DNS servers to the box, this setting is stored on the following file

# is the systemd-resolved stub resolver.
# run "systemd-resolve --status" to see details about the actual nameservers.


But we cant manually update this file with out own DNS servers, lets investigate

Cartoon of a detective investigate following footprints | Premium ...
ls -l /etc/resolv.conf

its a symlink to the another system file


When you take a look at the directory where that file resides, there are two files

When you look at the other file you will see that /run/systemd/resolve/resolv.conf is the one which really is carrying the external name servers

You still can’t manually edit This file, and it gets updated by whatever the IPs provided as DNS servers via DHCP. netplan will dictate the IPs based on the static DNS servers you configure on Netplan YAML file

i can see there two entries, and they are the default Linode DNS servers discovered via DHCP, I’m going to keep them as is, since they are good enough for my use case

If you want to use your own servers here – Follow this guide

 Lets change the symlink to this file instead of the stub-resolve.conf

$ sudo ln -sf /run/systemd/resolve/resolv.conf /etc/resolv.conf

Now that its pointing to the right file

Lets restart the systemd-resolved

systemctl restart systemd-resolved

Now you can resolve DNS and install packages, etc

Docker compose script file for the PI-Hole

sudo mkdir /Docker_Images/
sudo mkdir /Docker_Images/Piholev6/

Lets navigate to this directory and start setting up our environment

nano /Docker_Images/Piholev6/docker-compose.yml
version: '3.4'

    container_name: pihole_v6
    image: pihole/pihole:latest
    hostname: Multicastbits-DNSService
      - "53:53/tcp"
      - "53:53/udp"
      - "8080:80/tcp"
      - "4343:443/tcp"
      TZ: America/New_York
      WEBPASSWORD: F1ghtm4_Keng3n4sura
      enable_ipv6: "true"
      ServerIPv6: 2600:3c03::f03c:92ff:feb9:ea9c
       - '${ROOT}/pihole/etc-pihole/:/etc/pihole/'
       - '${ROOT}/pihole/etc-dnsmasq.d/:/etc/dnsmasq.d/'
      - NET_ADMIN
    restart: always

      name: Piholev6
      name: Piholev6

Lets break this down a littlebit

  • Version – Declare Docker compose version
  • container_name – This is the name of the container on the docker container registry
  • image – What image to pull from the Docker Hub
  • hostname – This is the host-name for the Docker container – this name will show up on your lookup when you are using this Pi-hole
  • ports – What ports should be NATed via the Docker Bridge to the host VM
  • TZ – Time Zone
  • DNS1 – DNS server used with in the image
  • DNS2 – DNS server used with in the image
  • WEBPASSWORD – Password for the Pi-Hole web console
  • ServerIP – Use the IPv4 address assigned to the VMs network interface(You need this for the Pi-Hole to respond on the IP for DNS queries)
  • IPv6 – Enable Disable IPv6 support
  • ServerIPv6 – Use the IPv4 address assigned to the VMs network interface (You need this for the Pi-Hole to respond on the IP for DNS queries)
  • volumes – These volumes will hold the configuration data so the container settings and historical data will persist reboots
  • cap_add:- NET_ADMIN – Add Linux capabilities to edit the network stack – link
  • restart: always – This will make sure the container gets restarted every time the VM boots up – Link
  • networks:default:external:name: Piholev6 – Set the container to use the network bridge we created before

Now lets bring up the Docker container

docker-compose up -d

-d switch will bring up the Docker container in the background

Run ‘Docker ps’ to confirm

Now you can access the web interface and use the Pihole

verifying its using the bridge network you created

Grab the network ID for the bridge network we create before and use the inspect switch to check the config

docker network ls
docker network inspect f7ba28db09ae

This will bring up the full configuration for the Linux bridge we created and the containers attached to the bridge will be visible under the “Containers”: tag


I manually configured my workstations primary DNS to the Pi-Hole IPs

Updating the docker Image

Pull the new image from the Registry

docker pull pihole/pihole

Take down the current container

docker-compose down

Run the new container

docker-compose up -d

Your settings will persist this update

Securing the install

now that we have a working Pi-Hole with IPv6 enabled, we can login and configure the Pihole server and resolve DNS as needed

but this is open to the public internet and will fall victim to DNS reflection attacks, etc

lets set up firewall rules and open up relevant ports (DNS, SSH, HTTPS) to the relevant IP addresses before we proceed

Disable IPtables from the docker daemon

Ubuntu uses UFW (uncomplicated firewall) as an obfuscation layer to make things easier for operators, but by default, Docker will open ports using IPtables with higher precedence, Rules added via UFW doesn’t take effect

So we need to tell docker not to do this when launching a container so we can manage the firewall rules via UFW

This file may not exist already if so nano will create it for you

sudo nano /etc/docker/daemon.json

Add the following lines to the file

"iptables": false

restart the docker services

sudo systemctl restart docker

now doing this might disrupt communication with the container until we allow them back in using UFW commands, so keep that in mind.

Automatically updating Firewall Rules based on the DYN DNS Host records

we are going to create a shell script and run it every hour using crontab

Shell Script Dry run

  • Get the IP from the DYNDNS Host records
  • remove/Cleanup existing rules
  • Add Default deny Rules
  • Add allow rules using the resolved IPs as the source

Dynamic IP addresses are updated on the following DNS records


Lets start by creating the script file under /bin/*

sudo touch /bin/
sudo chmod +x /bin/
sudo nano /bin/

now lets build the script

now=$(date +"%m/%d/%T")
#Get the network IP using dig
Network01_CurrentIP=`dig +short $DYNDNSNetwork01`
Network02_CurrentIP=`dig +short $DYNDNSNetwork02`
echo "-----------------------------------------------------------------"
echo Network A WAN IP $Network01_CurrentIP
echo Network B WAN IP $Network02_CurrentIP
echo "Script Run time : $now"
echo "-----------------------------------------------------------------"
#update firewall Rules
#reset firewall rules
sudo ufw --force reset
#Re-enable Firewall
sudo ufw --force enable
#Enable inbound default Deny firewall Rules
sudo ufw default deny incoming
#add allow Rules to the relevant networks
sudo ufw allow from $Network01_CurrentIP to any port 22 proto tcp
sudo ufw allow from $Network01_CurrentIP to any port 8080 proto tcp
sudo ufw allow from $Network01_CurrentIP to any port 53 proto udp
sudo ufw allow from $Network02_CurrentIP to any port 53 proto udp
#add the ipV6 DNS allow all Rule - Working on finding an effective way to lock this down, with IPv6 rick is minimal
sudo ufw allow 53/udp
#find and delete the allow any to any IPv4 Rule for port 53
sudo ufw --force delete $(ufw status numbered | grep '53*.*Anywhere.' | grep -v v6 | awk -F"[][]" '{print $2}')
echo "--------------------end Script------------------------------"

Lets run the script to make sure its working

I used a online port scanner to confirm

Setup Scheduled job with logging

lets use crontab and setup a scheduled job to run this script every hour

Make sure the script is copied to the /bin folder with the executable permissions

using crontab -e (If you are launching this for the first time it will ask you to pick the editor, I picked Nano)

crontab -e

Add the following line

0 * * * * /bin/ >> /var/log/PIHolefwruleupdate_Cronoutput.log 2>&1
Lets break this down
0 * * * *

this will run the script every time minutes hit zero which is usually every hour


Script Path to execute

/var/log/PIHolefwruleupdate_Cronoutput.log 2>&1

Log file with errors captured

Reducing Dell PowerEdge (PE) 2950/2900/2800 II/III fan noise – Fan mod + BMC firmware mod (Noob friendly guide)

Dell 2950 III is one of the best bang for the buck servers you can find on Ebaym but there is one problem this server runs very loud by design.

Example (video Credit David Lohle)

I have my lab setup in my room so I had to do something about this.

After wondering around in the OSMA, DRAC and BIOS with no luck, I turned to almighty Google for help.

Turns out Dell decided not to expose the BMC’s fan controller settings to the users. It’s baked in to the firmware.

Reducing the noise involves two mods, hardware and firmware.

  1. Fan MOD – Lower the Fan speeds to reduce the noise
  2. Firmware mod – Lowering the BMC fan rpm thresholds


I stress tested the server after the mod, check here for details – Dell PE 2950 Stress test

01. Fan MOD – Lower the Fan speeds to reduce the noise

I stumbled upon this post on the “Blind Caveman’s blog”. –

Apparently he had success with adding a 47ohm resistor in line to all 4 intake fans, he has a very comprehensive guide on the mod.

I’m just going to put the summery of what I did. (Props to Caveman for coming up with this solution)

Items you need

  • 4pc of 47ohm ½ watt resistors. (Radio shack $1.49)
  • Heat Shrink. (Radio shack $4.59)
  • Soldering iron.
Note : You can drop the resistor value to increase the fan voltage

10v = 12 ohms
9v = 2020 ohms
8v = 3030 ohms
7v = 42
42 ohms

Fan Mod – Steps

01. Remove the cover.

02. Remove the fan by pulling the orange tabs and gently lifting up.


 03. Remove the wire clip cut the “Red” wire and solder the resistor in line with the wire.


    Red Wire

04. Re-seat the fans back on the server. (be careful not to let it touch the heat sink right next to it)


    Watch out for the Heat-sink

I just modded the intake fans, OP suggest to mod the PSU fans but I don’t think you need to mess with the power supply fans for 3 reasons.

        • It’s not going to make a huge difference. (my PE is running below 52db with just the intake fans modded)
        • PSU is Expensive to replace. (on Ebay PSU is around $100 but four Dell 2950 Fans cost less than $10)
        • I believe the PSU units should run very cool and efficient as much as possible.


      So after the mod, I booted up the server, it was running significantly quieter. BUT… yes there’s a huge but….

      Issue 01 – OSMA Errors and fan speed issues

      The fan speeds were ramping up and down every few minutes.
      When i monitored the fan speeds via DRAC and it showed an error with the fans failing since the idle rpm is lower than the minimum rpm threshold.

      What is  happening

      the BMC lower the fan RPM after the initial boot, since the resistor is in place the lowest RPM is around 1800 and the default minimum RPM error threshold is 2250rpm so the BMC panics, spins the fans back up to 100%, lower them again since the error is cleared. So on. it was going on in a never ending cycle of annoyingness.

      So after some more google fu. I found a post written by a German “Artificial intelligence researcher” who faced the same issue after he swapped out the dell fans with lower RPM ones and since dell refused to help him fix it, he engineered his own fix for this by modifying the BMC firmware to reduce the minimum rpm threshold (how cool is that).

      His name is Arnuschky – Link | Post link

      His post is well written to the point (Kudos to you sir) but its not very noob friendly. 🙁
      So I’m going to make a step by step guide using his post as reference with few more additions, for anyone who is new to open source and messing with dell firmwares.

      02. Firmware mod – Lowering the BMC fan rpm thresholds

      The solution explained-

      Arnuschky figured out the exact setting in the BMC’s firmware, the check-sums etc to modify the fan rpm thresholds and wrote a very nifty script to help us modify the values on a downloaded firmware file.

      What is BMC (board management controller)

      • Among many other things, fans are controlled by the BMC and the fan curve and all the values are baked in to the firmware.

      • BMC (board management controller) by design will ramp up the RPM of the fans every time you add more hardware to the system such as – Add-on cards, RAM, HDD’s, etc

      What is IPMI

      • Intelligent Platform Management Interface, this tool set can be easily installed on any linux distribution and after you enable IPMI in the BIOS (DRAC interface) you can query sensory data from BMC and configure parameters on the BMC.


      Things you should know –

      • This worked for many people including me. Myself nor anyone involved will not be held responsible for any damages caused by proceeding with the firmware mod.

      • You cannot perform this mod on ESXI. But if you are running a base OS like Redhat/CentOS/Ubuntu you should be good to go.

      • You cannot flash the firmware using a VM (If you know a way please let us know)

      • To modify the firmware you have to be on a Linux server, you can technically flash the modified firmware from windows server. I will add the details later in the post

      Packages required

      • BMC Firmware file – Dell Drivers and support
      • IPMI tools
      • glibc.i686 (If you are on a 64bit OS)

      I have Esxi 5.5 installed on the Dell server so I used a Cent OS 6.4 installation running off a USB stick to do the modifications and flashing

      Enable IPMI on the DRAC interface

      • You can do this by logging in to the DRAC web interface or though the bios screen
      • Press ctrl+E during the post screen to access the DRAC card configuration screen and Enable IPMI

      Setting up IPMI Tools

      yum install OpenIPMI OpenIPMI-tools

      StartEnable the Service

      chkconfig ipmi on
      service ipmi start

      Run the following commands to see if IPMI is working

      ipmitool sdr type Temperature
      Temp             | 01h | ok  |  3.1 | -48 degrees C
      Temp | 02h | ok | 3.2 | -42 degrees C
      Temp | 05h | ok | 10.1 | 40 degrees C
      Temp | 06h | ok | 10.2 | 40 degrees C
      Ambient Temp | 08h | ok | 7.1 | 27 degrees C
      CPU Temp Interf | 76h | ns | 7.1 | Disabled
      ipmitool sdr type Fan
      FAN 1 RPM        | 30h | ok  |  7.1 | 4200 RPM
      FAN 2 RPM | 31h | ok | 7.1 | 4200 RPM
      FAN 3 RPM | 32h | ok | 7.1 | 4200 RPM
      FAN 4 RPM | 33h | ok | 7.1 | 4200 RPM
      FAN 5 RPM | 34h | ok | 7.1 | 4200 RPM
      FAN 6 RPM | 35h | ok | 7.1 | 4200 RPM
      Fan Redundancy | 75h | ok | 7.1 | Fully Redundant

      Install glibc.i686

      yum install glibc.i686

      Firmware Flash program is 32bit and it will fail with the following warning on 64bit OS

      /lib/ bad ELF interpreter: No such file or directory

      Download the relevant firmware file

      • Visit –

      • Enter your service tag

      • Select OS version – Redhat or any other linux flavor (This will allow you to download the .bin file containing the firmware, this is what we need to modify the values)

      To save you time here’s the link for the Dell PE 2950 II, BMC firmware V2.50 – direct link

      mkdir bmcfwmod
      cd bmcfwmod #create project directory
      wget ""

      Set permissions and extract the firmware .bin file

      chmod 755 BMC_FRMW_LX_R223079.BIN                              # make executable
      sudo mkdir bmc_firmware # create dir as root
      sudo ./BMC_FRMW_LX_R223079.BIN --extract bmc_firmware # yes, you have to do this as root! :(
      cd bmc_firmware

      Note : You have to extract the bin file in-order to proceed..
      Above commands will extract the firmware bin file, in to the bmc_firmware folder.
      Check inside the folder to see if you have a file called /payload/bmcflsh.dat.
      If not that means your system is not compatible with this mod. If yes, please continue.

      Patching the firmware file

      You should be in the bmc_firmware directory created above

      Download and run the script

      –no-check-certificate switch is used to get around the cert issue due to the github domain name mismatch

      wget " --no-check-certificate"
      chmod 755 # set permissions
      ./ payload/bmcflsh.dat #execute the py script on the bmcflsh.dat file

      The script will prompt you with the following screen

      Select your server model in this case I selected Dell PowerEdge 2950 = number 3

      Then it will prompt you to select the fans and adjust the threshold.
      On the DRAC interface the intake fans shows up numbered 1-4,
      I edited the values for the fans 1 thorough 4 (Only the intake fans will be effected)

      Setting the value

      When you select the fan number it will ask you to enter the value for the new threshold
      This should be entered in multiples of 75 for example the default value is 2025 which is a 27×75 so the default value is 27
      So to reduce the threshold value you need to enter something lower than 27
      I choose 18 as the value, this will drop my threshold to 1350rpm (18×75=1350)

      Saving the changes

      After editing the appropriate values, enter “W” to write the changes to the firmware as prompted.
      This will update the bmcflsh.dat with the modified values

      Flashing the modified firmware

      If you are on a 64bit OS make sure you have the glibc.i686 package installed

      LD_LIBRARY_PATH=./hapi/opt/dell/dup/lib:$LD_LIBRARY_PATH ./bmcfl32l -i=payload/bmcflsh.dat –f

      This will map the necessary Shared Libraries and execute the bmcfl32l to flash the firmware file

      Fans will rev up and stop for a brief moment during the update, don’t worry it will spool up again in a second.
      You do not need to reboot to see the changes, but do a reboot just in case.
      So there you go, your Dell 2950 should be purring away on the shelf silently.

      You should disable the IPMI on DRAC since it is a big security risk.

      Tested for more 24 hours

      Update: Dell PE 2950 Stress test after the mod

      • No noticeable temperature difference with the components
      • No post errors
      • No OMSA or DRAC errors

      Noise Level comparison

      Before the mod

      After the mod

      Its a very long post and its almost morning. so forgive me for any grammar, spelling or formatting mistakes.

      Until next time…….

      Hacking WatchGuard Firebox to Run pfsense- nanoBSD

      Hi Internetz, its been a while…

      So we had an old Firebox X700 laying around in office gathering dust. I saw this forum post about running m0nowall on this device. since pfsense is based on m0nowall, I googled around to find a way to install pfsense on the device and found several threads on pfsense forums.
      It took me a little while to comb through thousands of posts to find a proper way to go about this. And some more time was spent on troubleshooting the issues I faced during the installation and configuration. So I’m putting everything I found on this post, to save you the time spent googling around. This should work for all the other firebox models as well.

      What you need :


      • Firebox
      • Female to Female Serial Cable – link
      • 4GB CF Card (We can use 1Gb, 2Gb but personally I would recommend at-least 4GB)
      • CF Card Reader


      • pfsense NanoBSD
      • physdiskwrite –  Download
      • TeraTerm Pro Web – Enhanced Telnet/SSH2 Client – Download

      The firebox X700

      This is basically a small X86 PC. we have a Intel Celeron CPU running at @1.2Ghz with 512MB Ram. The system boots using a CF card with watchguard firmware
      The custom Intel motherboard used in the device does not include a VGA or a DVI port. we have to use the serial port for all the communications with the device

      There are several methods to run pfsense on this device.


      Install PF sense on a PC and Plug the HDD to the firebox.

      This requires a bit more of a effort cause we need to change the boot order on bios. and its kinda hard to find IDE laptop HDD’s these days

      CF card

      This is very straight forward Method. We are basically swapping out the CF card already installed on the device and booting pfsense from it.

      In this tutorial we are using the CF card method

      Installing PFsense

      • Download the relevant pfsense image

      Since we are using a CF card we need to use the PFsense version built to work on embedded devices.

      NanoBSD version is built specially to be used with CFcards or any other storage media’s that have limited read write life cycle

      Since we are using a 4GB CF card, we are going to use the 4G image

      • Flashing the nanoBSD image to the CF card

      Extract the physdiskwrite program and run the PhysGUI.exe
      This software is written in German i think but operating it is not that hard

      Select the CF card from the list.

      Note : if you are not sure about the disk device ID. use diskpart and determine the disk ID

      Load the ISO file
      Right click on the Disk “Image laden > offnen”

      select the ISO file from the “open file” window
      program will prompt you with the following dialog box


      Select the remove 2GB restriction and click “OK”
      It will warn you about the disk being formatted (I think), click yes to start the disk flashing process. a CMD window will open and show you the progress

      • Installing the CF card on the Firebox

      Once the flashing process is completed, open up the Firebox and Remove the drive cage to gain access to the installed CF Card

      Remove the protective glue and replace the card with the new CF card flashed with pfsense image.

      • Booting up and configuring PFsense

      since Firebox does not have any way to connect to a display or any peripheral ports. We need to use a serial connection for communicating with the device

      Install “teraTerm pro web” program we downloaded earlier.

      I tried using putty and many other telnet clients didn’t work properly

      Open up the terminal window

      Connect the firebox to the PC using the serial cable, and power it up

      Select “Serial” and select the com port the device is connected to and click OK(You can check this in device manager)

      Many other tutorials says to change the baud rates. but defaults worked just fine for me
      Since we already flashed the PFsense image to the CF card we do not need to install the OS

      By now on the terminal window you should be having the PF sense configuration details. just as with a normal fresh install.

      It will ask you to setup VLan

      Assign the WAN, LAN, OPT1 interfaces.

      ON X700 interface names are as follows

      Please refer to pfsense Docs for more info on setting up

      After the initial config is completed. you do not need the console cable and Tera Term
      you will be able to access the PFsense via the web-interface and good ol SSH via the LAN IP

      Addtional configuration

      • Enabling the LCD panel

      All firebox units have a LCD panel in front
      We can use the pfsense LCDproc-dev package to enable and display various information

      Install the LCDproc-dev Package via the package Manager

      Go to Services > LCDProc

      Set the settings as follows

      Hope this article helped you guys.Dont forget to leave a comment with your thoughts

      Sources –

      Crucial M4 SSD New Firmware and how to Flash using a USB thumb drive !!Update!!

      well i think the Title pretty much speak for it self..but any how…Crucial released a new Firmware for the M4 SSD’s and apparently its suppose to make the drive 20% faster…i updated mine no issues. and i didn’t brick it so its all good here hehee.. Tongue

      I looked up some Benches from reviews from the time of release and compared them with the benchmarks i did after the FW update, i do get around 20% more increase just like they SAY !!!
      Crucial’s Official Release Notes:

      “Release Date: 08/25/2011

      Change Log:

          Changes made in version 0002 (m4 can be updated to revision 0009 directly from either revision 0001 or 0002)
          Improved throughput performance.
          Increase in PCMark Vantage benchmark score, resulting in improved user experience in most operating systems.
          Improved write latency for better performance under heavy write workloads.
          Faster boot up times.
          Improved compatibility with latest chipsets.
          Compensation for SATA speed negotiation issues between some SATA-II chipsets and the SATA-III device.
          Improvement for intermittent failures in cold boot up related to some specific host systems.”

      Firmware Download:

      to install this via a pen drive with out wasting a blank cd..I know they are like really really cheap but think!!!! how many of you have blank cds or DVDs with you now a days ???

      to do this we are gonna use a niffty lil program called UNetbootin
      ofcourse you can use this to boot any linux distro from a pen drive.its very easy actually, if you need help go check out the guides on the UNetbootin website

      so here we go then…

      * First off Download –

      * Run the program
      * Select DiskImage Radio button (as shown on the image)
      * browse and select the iso file you downloaded from crucial
      * Type – USB Drive
      * select the Drive letter of your Pendrive
      * Click OK!!!


      *Go to bios and put your SSD in to IDE (compatibility) mode ** this is important
      *Boot from your Pen drive
      *Follow the instructions on screen to update

      and Voila

      ****remember to set your SATA controller to AHCI again in Bios / EFI ****


      SATA 3 Benchmark.

      SATA 2 Benchmark
      Well i messed around with some Benchmark programs here are the results
