Im going to base this off my VRF Setup and Route leaking article and continue building on top of it

Lets say we need to advertise connected routes within VRFs using IGP to an upstream or downstream iP address this is one of many ways to get to that objective

For this example we are going to use BGP to collect connected routes and advertise that over OSPF

Setup the BGP process to collect connected routes

router bgp 65000
 router-id 10.252.250.6
 !
 address-family ipv4 unicast
 !
 neighbor 10.252.250.1
!
vrf Tenant01_VRF
 !
 address-family ipv4 unicast
  redistribute connected
!
vrf Tenant02_VRF
 !
 address-family ipv4 unicast
  redistribute connected
!
vrf Tenant03_VRF
 !
 address-family ipv4 unicast
  redistribute connected
!
vrf Shared_VRF
 !
 address-family ipv4 unicast
  redistribute connected

Setup OSPF to Redistribute the routes collected via BGP

router ospf 250 vrf Shared_VRF
 area 0.0.0.0 default-cost 0
 redistribute bgp 65000
interface vlan250
 mode L3
 description OSPF_Routing
 no shutdown
 ip vrf forwarding Shared_VRF
 ip address 10.252.250.6/29
 ip ospf 250 area 0.0.0.0
 ip ospf mtu-ignore
 ip ospf priority 10

Testing and confirmation

Local OSPF Database

Remote device

Advertising VRF Connected/Static routes via MP BGP to OSPF – Guide Dell S4112F-ON – OS 10.5.1.3
